Finer PT 10B1-32T/L Taper Lock Sprocket – 10B-1 Simplex – 5/8″ Pitch – 32 Teeth – 2012 Bush

The Finer PT 10B1-32T/L is a 32 tooth taper lock sprocket for 10B-1 simplex British Standard roller chain – 5/8″ (15.88mm) pitch. It has a 162mm pitch circle diameter (PCD) and a 168.9mm outside diameter. It is bored to take a 2012 taper lock bush.

Taper lock sprockets locate on the shaft through a separate tapered bush. The bush carries the shaft bore and keyway – so one sprocket suits a range of shaft sizes – pulls up concentric as the screws are tightened and comes off cleanly for maintenance. All Finer sprockets are engineered in accordance with ISO 9000 standards.

Dimensions:

• Hub diameter (dm): 90 mm
• Overall length (A): 31.75 mm
• Tooth width (B1): 9.1 mm
• Tooth radius (r3): 16 mm
• Radius width (C): 1.6 mm
• Construction type: Type 1 as drawn on the spec sheet
• Approx. weight: 1.63 kg
• Chain: 5/8″ (15.88 mm) pitch – 9.65 mm inside width – 10.2 mm roller diameter

BS / ASA interchange (5/8″ pitch – BS 10B-1 and ASA 50-1): BS and ASA have identical plate thickness and roller diameters – both are interchangeable.

Please note: this sprocket is bored to take a 2012 taper lock bush – the bush is not included. When requesting a quote – include your shaft size so the matching bush can be supplied.

Downloads:

• Finer PT 10B Taper Lock Sprockets Spec Sheet (PDF)
• Finer PT Sprockets BS / ASA Interchange Chart (PDF)

Supplied by Finer Power Transmissions.
