Images are for illustrative purposes only. Actual product may vary.
IKO NA4824 Machined Needle Roller Bearing 120x150x30mm (With Inner Ring)
IKO NA4824 machined-type needle roller bearing, with inner ring. Bore 120mm, OD 150mm, width 30mm. High radial load capacity.
Product successfully added to the Quote List
- High running accuracy and rigidity for demanding industrial drives
- IKO (Nippon Thompson) precision manufacture to JIS standards
- Machined-type needle roller bearing - thick, rigid machined and ground outer ring
- Matching inner ring: LRT 12013030
- Supplied with an integral inner ring for mounting on unhardened shafts
- Very high radial load and shock capacity in a compact cross section
| Brand | IKO |
|---|---|
| Bearing Type | Machined Needle Roller Bearing |
| Series | NA |
| Measurement System | Metric |
| Inner Diameter (Bore) | 120 mm |
| Outer Diameter | 150 mm |
| Width | 30 mm |
| Configuration | With Inner Ring |
| Material | Chrome Bearing Steel |
| Dynamic Load Rating (Cr) | 96900 N (96.9 kN) |
| Static Load Rating (C₀) | 259000 N (259.0 kN) |
| Limiting Speed (Grease) | 1800 rpm |
| Limiting Speed (Oil) | 3000 rpm |
| Compatible Inner Ring | LRT12013030 |
| Weight | 1.3 kg |
| Features & Benefits | High running accuracy and rigidity for demanding industrial drives IKO (Nippon Thompson) precision manufacture to JIS standards Machined-type needle roller bearing - thick, rigid machined and ground outer ring Matching inner ring: LRT 12013030 Supplied with an integral inner ring for mounting on unhardened shafts Very high radial load and shock capacity in a compact cross section |
The IKO NA4824 is a machined-type needle roller bearing with its own inner ring, for a 120mm shaft (metric series). Machined and ground from solid bearing steel, it has a thick, rigid outer ring that carries very high radial loads and shock in a compact section. Boundary dimensions 120 x 150 x 30mm.
The integral inner ring provides a ready raceway so the bearing can mount directly on a soft or unhardened shaft. Suitable for high radial loads in gearboxes, pumps, and industrial machinery. Compatible inner ring: LRT 12013030. Manufactured by IKO (Nippon Thompson), Japan.
