Images are for illustrative purposes only. Actual product may vary.
IKO TAM815 Needle Roller Bearing 8x15x15mm (Closed End)
IKO TAM815 drawn cup needle roller bearing, closed end. Bore 8mm, OD 15mm, width 15mm.
Product successfully added to the Quote List
- Closed end seals and protects the end of the shaft
- Drawn cup (shell type) needle roller bearing - thin-walled deep-drawn outer shell forms the raceway
- High radial load capacity from the needle roller complement
- IKO (Nippon Thompson) precision manufacture to JIS standards
- Lowest sectional height of any needle roller bearing for a very compact arrangement
- Maximum operating temperature approximately 140C
- Press-fit into the housing bore - no axial location fixtures required
| Brand | IKO |
|---|---|
| Bearing Type | Drawn Cup Needle Roller Bearing |
| Series | TA |
| Measurement System | Metric |
| Inner Diameter (Bore) | 8 mm |
| Outer Diameter | 15 mm |
| Width | 15 mm |
| Configuration | Closed End |
| Material | Chrome Bearing Steel |
| Dynamic Load Rating (Cr) | 5780 N (5.78 kN) |
| Static Load Rating (C₀) | 5570 N (5.57 kN) |
| Limiting Speed (Grease) | 27000 rpm |
| Limiting Speed (Oil) | 45000 rpm |
| Weight | 0.0101 kg |
| Features & Benefits | Closed end seals and protects the end of the shaft Drawn cup (shell type) needle roller bearing - thin-walled deep-drawn outer shell forms the raceway High radial load capacity from the needle roller complement IKO (Nippon Thompson) precision manufacture to JIS standards Lowest sectional height of any needle roller bearing for a very compact arrangement Maximum operating temperature approximately 140C Press-fit into the housing bore - no axial location fixtures required |
The IKO TAM815 is a drawn cup (shell type) needle roller bearing with a closed end, for a 8mm shaft (metric series). Its thin-walled, deep-drawn outer shell forms the outer raceway, giving the lowest sectional height of any needle bearing while carrying high radial loads in a compact, economical package. Boundary dimensions 8 x 15 x 15mm.
The closed-end type is completely closed on one side, sealing and protecting the end of the shaft. The bearing is press-fitted into the housing bore, so no axial location fixtures are needed; maximum operating temperature approximately 140C. Manufactured by IKO (Nippon Thompson), Japan.
