Images are for illustrative purposes only. Actual product may vary.
NBR KM04 Bearing Lock Nut – M20X1
NBR KM04 bearing lock nut, thread M20X1. Outside diameter 32mm, width 6mm.
Product successfully added to the Quote List
- Bearing lock nut, M20X1 thread
- Clamps a bearing onto a shaft or adaptor sleeve
- NBR economy range, imported by Finer Power Transmissions for Australia
- Slotted for a hook or C-spanner
- Use with the matching MB04 tab washer to lock it in place
| Brand | NBR |
|---|---|
| Product Type | Lock Nut |
| Series | KM |
| Measurement System | Metric |
| Thread Size | M20X1 |
| Outer Diameter | 32 mm |
| Width | 6 mm |
| Matched Tab Washer | MB04 |
| Weight | 0.019 kg |
| Features & Benefits | Bearing lock nut, M20X1 thread Clamps a bearing onto a shaft or adaptor sleeve NBR economy range, imported by Finer Power Transmissions for Australia Slotted for a hook or C-spanner Use with the matching MB04 tab washer to lock it in place |
The NBR KM04 is a bearing lock nut with a M20X1 thread, 32mm outside diameter and 6mm width.
Lock nuts clamp a bearing onto a shaft or adaptor sleeve, and are used together with a matching tab washer (MB series) whose tab bends into one of the nut’s slots to prevent it loosening in service. Tightened with a hook or C-spanner.
Supplied under the NBR brand – an economy bearing and plain bearing range imported into Australia by Finer Power Transmissions.
