NBR PL-FL207 Thermoplastic 2-Bolt Flange Housing
NBR PL-FL207 thermoplastic 2-bolt flange housing. Suits 35mm shaft. Overall length 161mm, bolt centres 90mm.
Product successfully added to the Quote List
- Accepts NBR insert bearings
- Corrosion-resistant thermoplastic 2-bolt oval flange housing
- Ideal for washdown and wet environments
- NBR economy brand, imported by Finer Power Transmissions for Australia & New Zealand
- Supplied as housing only, insert ordered separately
| Brand | NBR |
|---|---|
| Bearing Type | 2-Bolt Oval Flange Housing |
| Series | PL-FL200 |
| Housing Type | Oval Flange (2-Bolt, Thermoplastic) |
| Material | Thermoplastic |
| Shaft Size | 35 mm |
| Overall Length (H) | 161 mm |
| Height (J) | 130 mm |
| Bolt Hole Centres (L) | 90 mm |
| Wall (A) | 34 mm |
| Bolt Hole Diameter (N) | 16 mm |
| Insert Width (E) | 44.4 mm |
| Features & Benefits | Accepts NBR insert bearings Corrosion-resistant thermoplastic 2-bolt oval flange housing Ideal for washdown and wet environments NBR economy brand, imported by Finer Power Transmissions for Australia & New Zealand Supplied as housing only, insert ordered separately |
NBR PL-FL207 Thermoplastic 2-Bolt Flange Housing
The NBR PL-FL207 is a moulded thermoplastic 2-bolt oval flange housing (corrosion resistant, ideal for washdown) for a 35mm shaft bearing.
Supplied as a housing only – the insert bearing is ordered separately. Supplied under the NBR brand – a cost-effective mounted bearing range imported into Australia and New Zealand by Finer Power Transmissions – offering reliable quality for industrial, agricultural and washdown applications.
