SS6311-2RS FG Stainless Steel Deep Groove Ball Bearing – 55x124x29mm

SS6311-2RS FG Stainless Steel Deep Groove Ball Bearing – 55x124x29mm

The SS6311-2RS FG is a stainless steel deep groove ball bearing from the ENC range built by BRL Bearings in Spain. With a bore diameter of 55 mm, outer diameter of 124 mm, and a width of 29 mm, this bearing conforms to ISO dimension standards and is a direct interchange for equivalent series bearings from other manufacturers.

Design & Construction

Manufactured by BRL Bearings – a Spanish specialist in high temperature rotation. Stainless steel rings and balls resist corrosion in damp and washdown conditions where a chrome steel bearing would rust. Standard radial internal clearance is fitted – the same as a general purpose bearing of the same size. Rubber 2RS seals on both sides keep water and washdown chemicals out of the raceways.

Performance

Rated for a basic static load capacity of 38.87 kN, this bearing delivers dependable load-carrying ability and long calculated service life under correct operating conditions. Permissible speed reaches 3425 rpm with grease lubrication. Supplied lubricated with a food grade grease and ready to install.

Typical Applications

• Applications with a high level of humidity
• Food and beverage processing machinery
• Washdown and cleaning equipment
• Dairy and beverage filling lines
• Marine and coastal installations
• Water treatment plant
• Commercial laundry equipment
• Packaging machinery
• Agricultural spraying and irrigation equipment
• General industrial and workshop machinery
